SUPER ERCOLE - verricello orizzontale

[418476] KIT B VITERIA SUPERERCOLE

[418500] KIT C LINGUETTE SUPERERCOLE

[418575] KIT D SEEGER SUPERERCOLE

[427806] KIT A GUARNIZIONI SUPERERCOLE

[601362] KIT PRIGIONIERO M8X45 #240

[601412] KIT PRIGIONIERO M10X538 #793

[630804] ALBERO SUPERERCOLE #780

[630823] ALBERO SUPERERCOLE #803

[630825] ALBERO SUPERERCOLE #768

[630833] DISTANZIALE SUPERERCOLE #759

[630888] CUSCINETTO AX3.5 7095 #775''

[630908] BICCHIERE ERCOLE H. #728 OTT

[630941] BUSSOLA ERCOLE H. #573A

[630943] BUSSOLA ERCOLE H. #573B

[630941] BUSSOLA ERCOLE H. #573A

[630943] BUSSOLA ERCOLE H. #573B

[630941] BUSSOLA ERCOLE H. #573A

[630943] BUSSOLA ERCOLE H. #573B

[630942] BUSSOLA ERCOLE H. #706

[631019] BARBOTIN 10 IMPRONTE PER ERCOLE V. #574A

[631039] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574B

[631053] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574G

[631056] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574I

[631065] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX5/SX7 14mm#574D

[631068] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574H

[631082] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmISO4565 #574E

[631085] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574L

[631088] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmDIN766 #574F

[631092] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574M

[631095] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574S

[631098] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574O

[631101] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574N

[631104] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574P

[631110] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574R

[631113] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574Q

[631019] BARBOTIN 10 IMPRONTE PER ERCOLE V. #574A

[631039] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574B

[631053] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574G

[631056] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574I

[631065] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX5/SX7 14mm#574D

[631068] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574H

[631082] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmISO4565 #574E

[631085] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574L

[631088] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmDIN766 #574F

[631092] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574M

[631095] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574S

[631098] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574O

[631101] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574N

[631104] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574P

[631110] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574R

[631113] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574Q

[631019] BARBOTIN 10 IMPRONTE PER ERCOLE V. #574A

[631039] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574B

[631053] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574G

[631056] BARBOTIN 8 IMPRONTE PER ERCOLE V. #574I

[631065] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX5/SX7 14mm#574D

[631068] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574H

[631082] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmISO4565 #574E

[631085] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574L

[631088] LOFRANS BARBOTIN Ercole(Orizz. &Vert. )/S.Ercole/SX7 16mmDIN766 #574F

[631092] BARBOTIN 6 IMPRONTE PER ERCOLE V. #574M

[631095] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574S

[631098] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574O

[631101] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574N

[631104] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574P

[631110] BARBOTIN 5 IMPRONTE PER ERCOLE V. #574R

[631113] BARBOTIN 7 IMPRONTE PER ERCOLE V. #574Q

[631408] COPRI FRENO ERCOLE V. #642

[631426] LOFRANS' O-RING 6895 PER S. ERCOLE #755

[631427] GUARNIZIONE DIA.6 LUNGHEZZA 535MM #798

[631447] Campana ERCOLE V. INOX #1070

[631490] CAMPANA SUPERERCOLE #789 CRO

[631543] Corona dentata Superercole #772

[631572] CUSCINETTO ANELLO CP 1,5 7095 #774''

[631583] COPERCHIO SUPERERCOLE #799 ALU

[631597] COPERCHIO SUPERERCOLE #754 BRO

[631648] Corpo riduttore SUPERERCOLE #756 Bianco

[631746] CUSCINETTO 6009 2Z #783

[631750] CUSCINETTO 6017 2Z #762

[631752] CUSCINETTO 6205 #714

[631757] CUSCINETTO 6212 2Z #777

[631769] CUSCINETTO 51109 #791

[631796] INNESTO FRONTALE ERCOLE H. #736 TRI

[631879] DISCO FRIZIONE SUPERERCOLE #748 TRI

[631883] DISCO FRIZIONE SUPERERCOLE #761 BAB

[631885] DISCO FRIZIONE SUPERERCOLE #750 TRI

[631886] DISCO FRIZIONE SUPERERCOLE #760 TRI

[631933] DISTANZIALE SUPERERCOLE #802

[631939] DISTANZIALE SUPERERCOLE #787

[631941] DISTANZIALE SUPERERCOLE #784

[631950] DISTANZIALE SUPERERCOLE #747

[631953] DISTANZIALE SUPERERCOLE #735

[632085] FLANGIA SUPERERCOLE #786

[632138] FLANGIA SUPERERCOLE #792

[632142] FLANGIA SUPERERCOLE #757

[632178] FRENO SUPERERCOLE #749

[632188] FLANGIA SUPERERCOLE #767

[633220] CUSCINETTO DB2012 #765

[633263] Ingranaggio Superercole #766

[633270] INGRANAGGIO CONICO SUPERERCOLE #781

[633274] INGRANAGGIO CONICO SUPERERCOLE #776

[633279] Ingranaggio Superercole #773

[633318] LEVA ERCOLE H. #733

[633428] LIVELLO OLIO SUPERERCOLE #626

[633440] MOTORE CA ERCOLE V. #641H 230V 5,5KW''

[633441] MOTORE CA ERCOLE V. #641AD 230V 5,0KW''

[633442] MOTORE CA ERCOLE V. #641D 230V 5,5KW''

[633443] MOTORE CA ERCOLE V. #641V 230V 5,5KW''

[633454] MOTORE CA ERCOLE V. #641AB 200V 4,0KW''

[633464] MOTORE CA ERCOLE V. #641M 230V 4,0KW''

[633465] MOTORE CA ERCOLE V. #641O 230V 4,0KW'' 60Hz

[633467] MOTORE CA ERCOLE V. #641N 230V 5,5KW''

[633474] MOTORE CA ERCOLE V. #641AG 380V 5,5KW''

[633483] MOTORE CA ERCOLE V. #641F 230/400V 4,0KW

[633487] MOTORE CA ERCOLE V. #641AA 400V 5,0KW''

[633488] MOTORE CA ERCOLE V. #641G 400V 5,5KW''

[633490] MOTORE CA ERCOLE V. #641Z 400V 7,5KW''

[633492] MOTORE CA ERCOLE V. #641L 415V 4,0KW''

[633494] MOTORE CA ERCOLE V. #641I 415V 5,5KW''

[633497] MOTORE CA ERCOLE V. #641S 440V 4,0KW''

[633498] MOTORE CA ERCOLE V. #641R 440V 5,5KW''

[635898] MOTORE CA ERCOLE V. #641N 3PH/50Hz/230V 5,5KW AUTOFRENO

[635905] SP-MOTORE CA ERCOLE V.#641AP 230V 5.5KW 3PH 60HZ AUTOFRENO

[635906] MOTORE CA ERCOLE V. #641G 400V 5,5KW AUTOFRENO

[633440] MOTORE CA ERCOLE V. #641H 230V 5,5KW''

[633441] MOTORE CA ERCOLE V. #641AD 230V 5,0KW''

[633442] MOTORE CA ERCOLE V. #641D 230V 5,5KW''

[633443] MOTORE CA ERCOLE V. #641V 230V 5,5KW''

[633454] MOTORE CA ERCOLE V. #641AB 200V 4,0KW''

[633464] MOTORE CA ERCOLE V. #641M 230V 4,0KW''

[633465] MOTORE CA ERCOLE V. #641O 230V 4,0KW'' 60Hz

[633467] MOTORE CA ERCOLE V. #641N 230V 5,5KW''

[633474] MOTORE CA ERCOLE V. #641AG 380V 5,5KW''

[633483] MOTORE CA ERCOLE V. #641F 230/400V 4,0KW

[633487] MOTORE CA ERCOLE V. #641AA 400V 5,0KW''

[633488] MOTORE CA ERCOLE V. #641G 400V 5,5KW''

[633490] MOTORE CA ERCOLE V. #641Z 400V 7,5KW''

[633492] MOTORE CA ERCOLE V. #641L 415V 4,0KW''

[633494] MOTORE CA ERCOLE V. #641I 415V 5,5KW''

[633497] MOTORE CA ERCOLE V. #641S 440V 4,0KW''

[633498] MOTORE CA ERCOLE V. #641R 440V 5,5KW''

[635898] MOTORE CA ERCOLE V. #641N 3PH/50Hz/230V 5,5KW AUTOFRENO

[635905] SP-MOTORE CA ERCOLE V.#641AP 230V 5.5KW 3PH 60HZ AUTOFRENO

[635906] MOTORE CA ERCOLE V. #641G 400V 5,5KW AUTOFRENO

[633505] MOTORE CC ERCOLE V. #640 24V 3,5KW''

[633530] MOLLA TIGRES #342

[633541] MOLLA ERCOLE V. #577

[633545] MOLLA FALKON #403

[634618] Perno Ercole H. #576

[634621] Perno freno Ercole orizzontale tipo B #745 inox

[634622] Perno freno Super Ercole #751 inox

[634626] Perno freno Ercole orizzontale #731 inox

[634627] Perno ingranaggio Super Ercole #764

[634632] Perno Super Ercole #771

[634670] Coperchio motore SUPERERCOLE #795 Bianco

[635287] STACCACATENA ERCOLE H. #729

[635312] Spina 4x20 #401

[635329] SALTARELLO ERCOLE H. #744

[635443] TAPPO OLIO 3/4 #758

[635508] VOLANTINO FRENO ERCOLE H. #579 CRO

[635551] VOLANTINO ERCOLE H. #692 CRO

[635553] VOLANTINO EMERGENZA ERCOLE H. #707 CRO

[635699] Vite senza fine Superercole #790

[635897] Guarnizione d.4mm, Ref.#650,785,698,677,717,794,622

Code	Description	Tensione	Tiro Massimo Istantaneo	Carico di lavoro Massimo al sollevamento	Assorbimento di corrente (A)	Velocità di recupero a carico (m/min)	Velocità Max. di recupero	Peso netto	Control Box	Pressione idraulica	Flusso idraulico	Tipo	Barbotin per catena	Modello Tipo
	VER. H. S. ERC. W.ALU T.A B+C 3500W/24V 16mm	24 V	5000 kg	950	240	14 m/min	28 m/min	235 kg	Incluso nella confezione	-	-	con campana	16 mm	Tipo A
	VER. H. S. ERC. W.ALU T.B B+C 3500W/24V 16mm	24 V	5000 kg	950	240	14 m/min	28 m/min	235 kg	Incluso nella confezione	-	-	con campana	16mm	tipo B
600671	VER. H. S. ERC. W.ALU T.D B+C 3500W/24V 16mm	24 V	5000 kg	950	240	14 m/min	28 m/min	235 kg	Included in package	-	-	With Drum	16 mm	Type D
600673	VER. H. S. ERC. W.ALU T.E B+C 5500W/3PH/400V 18mm	400 V	5500 kg	1200	-	17 m/min	17 m/min	235 kg	Switchboard available seperately	-	-	With Drum	18 mm	Type E
602487	VER. H. S. ERC. W.ALU T.A B+C HYD/ 14mm	-	6500 kg	1500	-	18 m/min	18 m/min	215 kg	-	200 bar	40 lt/min	With Drum	16 mm	Type A
	VER. H. S. ERC. W.ALU T.A B+C HYD/ 16mm	-	6500 kg	1500	-	18 m/min	18 m/min	215 kg	-	200 bar	40 lt/min	con campana	16mm	tipo A
	VER. H. S. ERC. W.ALU T.B B+C HYD/ 16mm	-	6500 kg	1500	-	18 m/min	18 m/min	215 kg	-	200 bar	40 lt/min	con campana	16mm	tipo B
	VER. H. S. ERC. W.ALU T.A B+C 5500W/400V 16mm	400 V	5500 kg	1200	-	17 m/min	17 m/min	235 kg	interruttore in vendita separatamente	-	-	con campana	16mm	tipo A
	VER. H. S. ERC. W.ALU T.B B+C 5500W/400V 16mm	400 V	5500 kg	1200	-	17 m/min	17 m/min	235 kg	interruttore in vendita separatamente	-	-	con campana	16mm	tipo B

SUPER ERCOLE - Horizontal Windlass
